Journal of Chinese Integrative Medicine ›› 2007, Vol. 5 ›› Issue (5): 517-520.doi: 10.3736/jcim20070508

• Original Clinical Research • Previous Articles     Next Articles

Effects of three compounds extracted from Tripterygium wilfordii Hook on angiogenesis in chick chorioallantoic membrane

Guo-fu Zhu1, Hui-qing Zhang2, Ai-jun Hou3, Yan-long Yang2, Qiu-shuang Li1, Cong-cong Zhang1

  1. 1. Teaching and Research Group of Chinese Materia Madica , School of Chinese Materia Madica , Shanghai University of Traditional Chinese Medicine , Shanghai 201203 ,China
    2. School of Traditional Chinese Medicine , Second Military Medical University , Shanghai 200433, China
    3. Teaching and Research Group of Pharmacognosy , School of Pharmacy , Fudan University , Shangha 200032, China
  • Online:2007-09-20 Published:2007-09-15

Objective: To investigate the effects of three compounds extracted from Tripterygium wilfordii Hook (TW) on angiogenesis in the chick chorioallantoic membrane (CAM).Methods: Fifty fresh Hongkong Mahua chicken eggs were divided into five groups: PBS-treated group, TW1-, TW2- and TW3-treated groups and Rg3-treated group. After disinfection, the eggs were incubated for six days in a constant temperature box with the temperature being controlled within 37.8 ℃, then exposed CAM, laid the filter papers with specimen on the CAM, and the eggs were incubated for another two days. CAM was fixed with the mixture of methyl alcohol and acetone at room temperature for about 15 min, and then cutting the CAM, taking photos and observing the angiogenesis in the CAM.Results: There were many CAM vessels in the PBS-treated group and the blood vessel net could be seen clearly. The number of CAM vessels in the TW1-, TW2- and TW3-treated groups (10 μg/egg) was much less than that in the PBS-treated group. Furthermore, the frame of the vessels was not clear, and the color was obscure. Inhibition rates of angiogenesis in the TW1-, TW2- and TW3-treated groups were 80%, 60% and 100% respectively, while the inhibition rate of angiogenesis in the Rg3-treated group (10 μg/egg) was only 10%.Conclusion: >TW1, TW2 and TW3 can obviously restrain the angiogenesis in CAM and still need further study.

CLC Number:

  • R917.77

Table 1

Effects of TW1, TW2 and TW3 on angiogenesis of CAM"

Group n Dose (μg/egg) Result Inhibition rate (%)
+ ++
PBS-treated 10 10 0 0
TW1-treated 10 10 2 3 5 80
TW2-treated 10 10 4 4 2 60
TW3-treated 10 10 0 1 9 100
Rg3-treated 10 10 9 1 0 10

Figure 1

Effects of TW1, TW2 and TW3 on angiogenesis in CAMA: PBS-treated group; B: TW1-treated group; C: TW2-treated group; D: TW3-treated group; E: Rg3-treated group."

[1] 岗艳云, 张正行 . 雷公藤及其单体的药理作用研究进展[J]. 中国药科大学学报, 1995,26(4):252-256
Gang YY, Zhang ZX . Progress research on Tripterygium wilfordii and its compounds[J]. Zhongguo Yao Ke Da Xue Xue Bao, 1995,26(4):252-256
[2] 陈星, 丰美福, 朱国英 . 雷公藤红素对血管平滑肌细胞内游离Ca2+和H+浓度的影响[J]. 中国中西医结合杂志, 1999,19(9):538-540
Chen X, Feng MF, Zhu GY . Effect of tripterine on concentration of free calcium and hydrogen in vascular smooth muscle cells[J]. Zhongguo Zhong Xi Yi Jie He Za Zi, 1999,19(9):538-540
[3] 黄煜伦, 周幽心, 周岱 , 等. 雷公藤红素抑制血管生成的实验研究[J]. 中华肿瘤杂志, 2003,25(5):429-432
Huang YL, Zhou YX, Zhou D , et al. Celastrol in the inhibition of neovascularization[J]. Zhonghua Zhong Liu Za Zhi, 2003,25(5):429-432
[4] 胡可斌, 刘志红, 刘栋 , 等. 雷公藤内酯醇抑制血管内皮细胞生长因子的表达与合成[J]. 中华医学杂志, 2001,81(18):1106-1109
Hu KB, Liu ZH, Liu D , et al. Triptolide inhibits vascular endothelial growth factor expression and production by endothelial cells[J]. Zhonghua Yi Xue Za Zhi, 2001,81(18):1106-1109
[5] 丁怡, 赵庆亮, 李勇刚 , 等. 雷公藤甲素对血管内皮细胞迁移活性的作用[J]. 四川大学学报 (医学版), 2005,36(3):347-350
Ding Y, Zhao QL, Li YG , et al. Effects of triptolide on migration of vascular endothelial cells[J]. Sichuan Da Xue Xue Bao (Yi Xue Ban), 2005,36(3):347-350
[6] 要庆平, 曾正陪, 张乃峥 . 雷公藤氯内酯醇(T4)对人脐带静脉内皮细胞产生内皮素的影响[J]. 中国医学科学院学报, 1995,17(3):228-229
Yao QP, Zeng ZP, Zhang NZ . Effect of tripehlorolide(T4) of Tripterygium wilfordii Hook on the production of endothelin-1 by endothelial cells of human umbilical vein[J]. Zhongguo Yi Xue Ke Xue Yuan Xue Bao, 1995,17(3):228-229
[7] 呼群, 宁涛, 苏秀兰 , 等. 鸡胚绒毛尿囊膜技术的改进[J]. 北京大学学报 (医学版), 2001,33(4):383-385
Hu Q, Ning T, Su XL , et al. Improvement of chick chorioallantoic membrane technique[J]. Beijing Da Xue Xue Bao (Yi Xue Ban), 2001,33(4):383-385
[8] 贺国安, 罗进贤, 张添元 , 等. 改进的鸡胚绒毛尿囊膜技术——无气室孵育法[J]. 中山大学学报(自然科学版), 2003,42(2):126-128
He GA, Luo JX, Zhang TY , et al. Improved chick chorioallantoic membrane technique—Incubation without air chamber[J]. Zhong Shan Da Xue Xue Bao (Zi Ran Ke Xue Ban), 2003,42(2):126-128
[9] Folkman J . Tumor angiogenesis: therapeutic implications[J]. N Engl J Med, 1971,285(21):1182-1186
[10] Jain RK, Schlenger K, Hockel M , et al. Quantitative angiogenesis assays: progress and problems[J]. Nat Med, 1997,3(11):1203-1208
doi: 10.1038/nm1197-1203 pmid: 9359693
[11] 陈彦凡, 陈少贤, 范小芳 , 等. 慢性低O2高CO2大鼠血管内皮生长因子表达及参一胶囊的影响[J]. 中国临床药理学与治疗学, 2004,9(6):709-712
Chen YF, Chen SX, Fan XF , et al. Expression of vascular endothelial growth factor in chronic hypoxia and hypercapnia rats and effects of SHENYI capsule[J]. Zhongguo Lin Chuang Yao Li Xue Yu Zhi Liao Xue, 2004,9(6):709-712
