Journal of Chinese Integrative Medicine ›› 2008, Vol. 6 ›› Issue (12): 1259-1262.doi: 10.3736/jcim20081210

• Original Experimental Research • Previous Articles     Next Articles

Effects of psoralen with long wave ultraviolet light on apoptosis and mitochondrial membrane potential in K562 cells

Shi-lin Huang, Nan-nan Chen(), Yang Xiang, Chen Zhang, Li Zhang, De-jie Zhang

  1. Department of Traditional Chinese Medicine and Hematology, Dalian 210th Hospital of People's Liberation Army, Dalian, Liaoning Province 116021, China
  • Received:2008-09-16 Online:2008-12-20 Published:2008-12-15


To study the effects of psoralen (PSO) with long wave ultraviolet light (PUVA) on apoptosis and mitochondrial membrane potential in K562 cells.


K562 cells were incubated with PSO in different concentrations (10, 20, 40 and 80 μg/ml for 24 hours) and irradiated without or with UVA (5 min). The changes in ultrastructure of the cells were observed under a transmission electron microscope. The apoptosis rates and the changes of mitochondrial membrane potentials were detected by flow cytometry. The factorial design and analysis of variance were used to analyze the interaction among the factors.


There were obvious ultrastructure changes related to apoptosis in K562 cells after being treated with PUVA (80 μg/ml). PSO, UVA and PUVA all increased the apoptosis rates and decreased the mitochondrial membrane potentials, and the effects of PUVA were stronger than those of PSO and UVA (P<0.01).


PUVA can induce the apoptosis of K562 cells and one of the pathways to the induction of apoptosis is to down-regulate the mitochondrial membrane potentials.

Key words: psoralen, photochemotherapy, leukemia, K562 cells, apoptosis, mitochondrial membrane potential

CLC Number:

  • R733.7

Figure 1

Ultrastructure change in K562 cells after 80 μg/ml PUVA treatment A: K562 cells before 80 μg/ml PUVA treatment (TEM, ×4 000); B: K562 cells after 80 μg/ml PUVA treatment (TEM, ×1 500); C: K562 cells after 80 μg/ml PUVA treatment (TEM, ×4 000)."

Table 1

Apoptosis ratios and MTP of K562 cells after 24-hour PUVA treatment (x±s)"

Group n Apoptosis ratio (%) MTP
Normal control 3 1.18±0.24 377.93±5.46
UVA 3 6.51±0.20** 262.00±3.51**
10 μg/ml PSO 3 1.41±0.11** 310.90±5.73**
20 μg/ml PSO 3 1.47±0.05** 193.43±9.81**
40 μg/ml PSO 3 1.52±0.12** 144.00±3.70**
80 μg/ml PSO 3 2.73±0.04** 122.23±8.94**
10 μg/ml PUVA 3 7.99±0.34**△△ 232.37±2.73**△△
20 μg/ml PUVA 3 9.23±0.39**△△ 132.83±1.34**△△
40 μg/ml PUVA 3 11.94±0.50**△△ 119.83±2.56**△△
80 μg/ml PUVA 3 17.84±0.57**△△ 117.50±0.98**△△
[1] Chen NN, Huang SL, Zhang DJ , et al. The effects of psoralen and ultraviolet A on NB4, HL-60 and K562 leukemia cell lines[J]. Zhongguo Zhong Yi Ji Zheng, 2007,16(4):444-446
doi: 10.3969/j.issn.1004-745X.2007.04.036
陈楠楠, 黄世林, 张德杰 , 等. 补骨脂素加长波紫外线对人白血病细胞株NB4、HL-60、K562作用的研究[J]. 中国中医急症, 2007,16(4):444-446
doi: 10.3969/j.issn.1004-745X.2007.04.036
[2] Wu SH, Zhang ZH, Zhao JB . Experimental study on antitumor activity of psoralen on mammary cancer cell line EMT6 in vitro and in vivo[J]. Zhongguo Zhong Yao Za Zhi, 1998,23(5):303-305
吴少华, 张仲海, 赵建斌 . 补骨脂素体内外抗癌活性的实验研究[J]. 中国中药杂志, 1998,23(5):303-305
[3] Carneiro Leite V, Ferreira Santos R, Chen Chen L , et al. Psoralen derivatives and longwave ultraviolet irradiation are active in vitro against human melanoma cell line[J]. J Photochem Photobiol B, 2004,76(1-3):49-53
doi: 10.1016/j.jphotobiol.2004.07.004
[4] Plumas J, Drillat P, Jacob MC , et al. Extracorporeal photochemotherapy for treatment of clonal T cell proliferations[J]. Bull Cancer, 2003,90(8-9):763-770
doi: 10.1038/sj.bjc.6601084 pmid: 14609767
[5] Efferth T, Fabry U, Osieka R . Induction of apoptosis, depletion of glutathione, and DNA damage by extracorporeal photochemotherapy and psoralen with exposure to UV light in vitro[J]. Anticancer Res, 2001,21(4A):2777-2783
[6] Halestrap AP, Kerr PM, Javadov S , et al. Elucidating the molecular mechanism of the permeability transition pore and its role in reperfusion injury of the heart[J]. Biochim Biophys Acta, 1998,1366(1-2):79-94
doi: 10.1016/S0005-2728(98)00122-4
