眼镜蛇毒细胞毒素缓释微球瘤内注射对裸鼠人肝癌皮下移植瘤的影响

doi:10.3736/jcim20090908

Abstract

Objective

To evaluate the safety and efficacy of intratumoral injection of polylactic-co-glycolic acid (PLGA) microspheres containing cobra venom cytotoxin in nude mice with transplanted human hepatoma.
Methods

Cytotoxic activity of cytotoxin from cobra venom was determined by using methyl thiazolyl tetrazolium method in vitro. Microspheres containing cobra venom cytotoxin were prepared with a double emulsion-solvent evaporation method. Forty BALB/c nude mice were inoculated subcutaneously in right flank with hepatoma BEL-7404 cells. Thirty-two mice whose tumor size reached about 1.0 cm in diameter, were randomly assigned into normal saline group, blank microsphers group, cytotoxin group and cytotoxin-PLGA group. Nude mice were intratumorally injected with normal saline, blank microspheres, cytotoxin or cytotoxin-PLGA microspheres respectively. Internal echo characteristics and blood flow of tumors were observed by high-frequency ultrasound every week after treatment. Twenty-six days after treatment, the tumors were removed to calculate the inhibition rate of tumor growth. The tumor, heart, liver and kidney tissues were obtained for histopathological examination.
Results

The cytotoxin separated and purified from crude cobra venom caused intense cytotoxic effects to the BEL-7404 cells in vitro. The diameter of PLGA microspheres containing cobra venom cytotoxin was about (34.45±9.85) μm. Encapsulation rate was up to (78.13±8.92)%, and cumulative amount of cobra venom cytotoxin released from the PLGA microspheres in vitro during 30 days was up to 84.3%. After intratumoral injection, tumor volumes and weights in the cytotoxin-PLGA group were lower than those in the normal saline group, with a tumor growth inhibition rate of 52.36%. Observed under a light microscope, most tumor tissues were necrotic. No obvious morphological change could be seen on the liver, kidney and heart tissues.
Conclusion: The above findings indicate that intratumoral injection of cytotoxin-PLGA microspheres has strong antitumor effect and can obviously lessen systemic toxicity, which may provide an effective and feasible method for hepatocellular carcinoma treatment.

Key words: Cobra venom cytotoxin, Liver neoplasms, Drug therapy, Delayed-action preparation, Mice, Nude

Yan Wang , Li-wu Lin, Zhi-kui Chen, En-sheng Xue, Xiao-dong Lin, Li-yun Yu, Zhen-hu Lin. Effects of intratumoral injection of microspheres containing cobra venom cytotoxin on transplanted human hepatoma in nude mice. Journal of Chinese Integrative Medicine, 2009, 7(9): 836-841.

/ / Recommend

Add to citation manager EndNote| Reference Manager|ProCite|BibTeX|RefWorks

URL: http://www.jcimjournal.com/EN/10.3736/jcim20090908

http://www.jcimjournal.com/EN/Y2009/V7/I9/836

TrendMD

Figures/Tables 7

Table 1

Figure 1

Figure 2

Table 2

Figure 3

Table 3

Figure 4

References 14

[1]	Abu-Sinna G, Esmat AY, Al-Zahaby AA, Soliman NA, Ibrahim TM . Fractionation and characterization of Cerastes cerastes cerastes snake venom and the antitumor action of its lethal and non-lethal fractions[J]. Toxicon, 2003,42(2):207-215 doi: 10.1016/S0041-0101(03)00138-7
[2]	Feofanov AV, Sharonov GV, Dubinnyi MA, Astapova MV, Kudelina IA, Dubovskii PV, Rodionov DI, Utkin YN, Arseniev AS . Comparative study of structure and activity of cytotoxins from venom of the cobras Naja oxiana, Naja kaouthia, and Naja haje[J]. Biochemistry (Mosc), 2004,69(10):1148-1157 doi: 10.1023/B:BIRY.0000046890.46901.7e
[3]	Oron U, Chaim-Matyas A, Ovadia M . Histopathological changes in WEHI-3B leukemia cells following intoxication by cytotoxin P4 from Naja nigricollis nigricollis venom[J]. Toxicon, 1992,30(9):1122-1126 doi: 10.1016/0041-0101(92)90058-D
[4]	Chen ZK, Lin LW, Lin Q, Zhuang QQ, He YM, Xue ES . Preparation and characterization of poly(lactide-co-glycolide acid) microspheres containing cytotoxin from Naja Naja Atra venom[J]. Zhongguo Sheng Hua Yao Wu Za Zhi, 2008,29(3):161-164
	陈志奎, 林礼务, 林琦, 庄权权, 何以敉, 薛恩生 . 眼镜蛇毒细胞毒素缓释微球制备及体外性质研究[J]. 中国生化药物杂志, 2008,29(3):161-164
[5]	Sapin A, Garcion E, Clavreul A, Laqarce F, Benoit JP, Menei P . Development of new polymer-based particulate systerms for anti-glioma vaccination[J]. Int J Pharm, 2006,309(1-2):1-5 doi: 10.1016/j.ijpharm.2005.10.046 pmid: 16386390
[6]	DeFail AJ, Chu CR, Izzo N, Marra KG . Controlled release of bioactive TGF-beta 1 from microspheres embedded within biodegradable hydrogels[J]. Biomaterials, 2006,27(8):1579-1585 doi: 10.1016/j.biomaterials.2005.08.013
[7]	Sun L, Wang Y, Liu ML, Xu MD . Recent developments on PLA/PLGA microspheres and its application[J]. Yao Wu Fen Xi Za Zhi, 2005,25(11):1409-1415
	孙磊, 王岩, 刘明理, 许鸣镝 . 聚乳酸/乳酸-乙醇酸共聚物微球制剂研究的新进展[J]. 药物分析杂志, 2005,25(11):1409-1415
[8]	Huang WD, Long DH, Gu HG . Explore of preparation and formulation parameters on BSA-PLGA microspheres[J]. Jie Pou Xue Yan Jiu, 2008,30(4):241-244
	黄婉丹, 龙大宏, 谷海刚 . BSA-PLGA缓释微球的制备及优化条件的探索[J]. 解剖学研究, 2008,30(4):241-244
[9]	Wang PP, Frazier J, Brem H . Local drug delivery to the brain[J]. Adv Drug Deliv Rev, 2002,54(7):987-1013 doi: 10.1016/S0169-409X(02)00054-6 pmid: 12384318
[10]	Li Q, Fan ZZ, Li XQ, Liu XH, Sun J, Gu W, Heng P, Gao H . Effects of interventional therapy with norcantharidin microsphere on hepatoma in rats and its mechanism[J]. J Chin Integr Med, 2006,4(4):378-383
	李琦, 范忠泽, 李先茜, 刘晓华, 孙珏, 顾伟 , Heng P, 高虹.去甲斑蝥素微球介入治疗大鼠肝癌疗效及其机制研究[J]. 中西医结合学报, 2006,4(4):378-383
[11]	Chen ZK, Lin LW, Yang FD, Weng XH, Cai HJ, Xue ES, Wang Y . Effects of interstitial chemotherapy using thermosensitive gel-coated ricin on hepatoma H22-bearing mice[J]. J Chin Integr Med, 2009,7(5):447-452 doi: 10.3736/jcim20090509
	陈志奎, 林礼务, 杨发端, 翁秀华, 蔡华晶, 薛恩生, 王艳 . 蓖麻毒素温敏型凝胶间质化疗对H22肝癌荷瘤小鼠的影响[J]. 中西医结合学报, 2009,7(5):447-452 doi: 10.3736/jcim20090509
[12]	Shive MS, Anderson JM . Biodegradation and biocompatibility of PLA and PLGA microspheres[J]. Adv Drug Deliv Rev, 1997,28(1):5-24 doi: 10.1016/S0169-409X(97)00048-3
[13]	Allen TM, Cullis PR . Drug delivery systems: entering the mainstream[J]. Science, 2004,303(5665):1818-1822 doi: 10.1126/science.1095833
[14]	Lesniak MS, Upadhyay U, Goodwin R, Tyler B, Brem H . Local delivery of doxorubicin for the treatment of malignant brain tumors in rats. Anticancer Res[J]., 2005,25(6B):3825-3831 doi: 10.3171/jns.2002.97.5.1173 pmid: 16312042

Related Articles 15

[1]	Yi Ran Hu, San Li Xing, Chuan Chen, Ding Zhu Shen, Jiu Lin Chen. Tiaoxin Recipe, a Chinese herbal formula, inhibits microRNA-34a expression in the APPswe/PS1ΔE9 mouse model of Alzheimer's disease. Journal of Integrative Medicine, 2019, 17(6): 404-409.
[2]	Xuan Liu, Li-juan Xiu, Jian-peng Jiao, Jing Zhao, Ying Zhao, Ye Lu, Jun Shi, Yong-jin Li, Min Ye, Yu-fang Gu, Xiao-wei Wang, Jing-yu Xu, Ci-an Zhang, Yong-ying Liu, Yun Luo, Xiao-qiang Yue. Traditional Chinese medicine integrated with chemotherapy for stage IV non-surgical gastric cancer: A retrospective clinical analysis. Journal of Integrative Medicine, 2017, 15(6): 469-475.
[3]	Bhesh Raj Sharma, Dong Wook Kim, Dong Young Rhyu. Korean Chungtaejeon tea extract attenuates weight gain in C57BL/6J-Lep ob/ob mice and regulates adipogenesis and lipolysis in 3T3-L1 adipocytes. Journal of Integrative Medicine, 2017, 15(1): 56-63.
[4]	Shi-li Jiang, Xu-dong Hu, Ping Liu. Immunomodulation and liver protection of Yinchenhao decoction against concanavalin A-induced chronic liver injury in mice. Journal of Integrative Medicine, 2015, 13(4): 262-268.
[5]	Xuanbin Wang, Ning Wang, Fan Cheung, Lixing Lao, Charlie Li, Yibin Feng. Chinese medicines for prevention and treatment of human hepatocellular carcinoma: Current progress on pharmacological actions and mechanisms. Journal of Integrative Medicine, 2015, 13(3): 142-164.
[6]	Elizabeth Abidemi Balogun, Sylvia Orume Malomo, Joseph Oluwatope Adebayo, Ahmed Adebayo Ishola, Ayodele Olufemi Soladoye, Lawrence Aderemi Olatunji, Olatunji Matthew Kolawole, Stephen Olubunmi Oguntoye, Abiola Samuel Babatunde, Oluwole Busayo Akinola . In vivo antimalarial activity and toxicological effects of methanolic extract of Cocos nucifera (Dwarf red variety) husk fibre. Journal of Integrative Medicine, 2014, 12(6): 504-511.
[7]	Md. Asadujjaman, Ahmed Ullah Mishuk, Md. Aslam Hossain, Utpal Kumar Karmakar. Medicinal potential of Passiflora foetida L. plant extracts: Biological and pharmacological activities. Journal of Integrative Medicine, 2014, 12(2): 121-126.
[8]	Marjan Nassiri-Asl, Taghi Naserpour Farivar, Esmail Abbasi, Hamid Reza Sadeghnia, Mehdi Sheikhi, Mina Lotfizadeh, Parisa Bazahang. Effects of rutin on oxidative stress in mice with kainic acid-induced seizure. Journal of Chinese Integrative Medicine, 2013, 11(5): 337-342.
[9]	Md. Khirul Islam, Imran Mahmud, Sanjib Saha, Asit Baron Sarker, Himangsu Mondal, A.S.M. Monjur-Al-Hossain, Md. Anisuzzman. Preliminary pharmacological evaluation of Alocasia indica Schott tuber. Journal of Chinese Integrative Medicine, 2013, 11(5): 343-351.
[10]	Sanjib Saha, Faroque Hossain, Md. Anisuzzman, Md. Khirul Islam. Pharmacological evaluation of Musa seminifera Lour. Fruit. Journal of Chinese Integrative Medicine, 2013, 11(4): 253-261.
[11]	Sunil A. Nirmal, Jayashri M. Ingale, Shashikant R. Pattan, Sanjay B. Bhawar. Amaranthus roxburghianus root extract in combination with piperine as a potential treatment of ulcerative colitis in mice. Journal of Chinese Integrative Medicine, 2013, 11(3): 206-212.
[12]	Lin Wang, Guan-liang Wang, Jia-han Liu, Di Li, De-zeng Zhu, Liang-neng Wu . Effects of ursolic acid in ameliorating insulin resistance in liver of KKAy mice via peroxisome proliferator-activated receptors α and γ. Journal of Chinese Integrative Medicine, 2012, 10(7): 793-799.
[13]	Yi-tao Zhao , Xin-guang Zhang , Li Bai , Li-qing Li , Jian-er Yu . Effects of Chinese herbal medicine Pingchuan Formula on airway inflammation, interferon-γ and interleukin-4 in mice with asthma. Journal of Chinese Integrative Medicine, 2012, 10(7): 807-813.
[14]	Mei-jiao Mao, Jun-ping Hu, Cong Wang, Yi-yi Zhang, Ping Liu. Effects of Chinese herbal medicine Guanxinkang on expression of PPARγ-LXRα-ABCA1 pathway in ApoE-knockout mice with atherosclerosis. Journal of Chinese Integrative Medicine, 2012, 10(7): 814-820.
[15]	Dong-mei Zhang, Li-xia Lou, Ai-ming Wu, Xi-ying Lü, Zhao-juan Hu, Yan-hong Zhang, Hong-fang Liu. Effects of Astragalus membranaceus and Potentilla discolor mixture on insulin resistance and its related mRNA expressions in KKAy mice with type 2 diabetes. Journal of Chinese Integrative Medicine, 2012, 10(7): 821-826.

Metrics

Viewed

Full text

Abstract

Cited

Shared

Discussed

Comments

Recommended 10

[1]	Wei-xiong Liang. Problems-solving strategies in clinical treatment guideline for traditional Chinese medicine and integrative medicine. Journal of Chinese Integrative Medicine, 2008, 6(1): 1-4
[2]	Jin-zhou Tian, Jing Shi, Xin-qing Zhang, Qi Bi, Xin Ma, Zhi-liang Wang, Xiao-bin Li, Shu-li Shen, Lin Li, Zhen-yun Wu, Li-yan Fang, Xiao-dong Zhao, Ying-chun Miao, Peng-wen Wang, Ying Ren, Jun-xiang Yin, Yong-yan Wang, Beijing United Study Group on MCI of the Capital Foundation of Medical Developments. An explanation on "guiding principles of clinical research on mild cognitive impairment (protocol)". Journal of Chinese Integrative Medicine, 2008, 6(1): 15-21
[3]	Hao Li, Ming-jiang Yao, Wen-ming Zhao, Jie Guan, Lin-lin Cai, Ling Cui. A randomized, controlled, double-blind trial of Huannao Yicong capsule in senile patients with mild cognitive impairment. Journal of Chinese Integrative Medicine, 2008, 6(1): 25-31
[4]	Yi-ting He, Qing-lin Zha, Jian-ping Yu, Yong Tan, Cheng Lu, Ai-ping Lv. Principal factor analysis of symptoms of rheumatoid arthritis and their correlations with efficacy of traditional Chinese medicine and Western medicine. Journal of Chinese Integrative Medicine, 2008, 6(1): 32-36
[5]	Jun Cai, Hua Wang, Sheng Zhou, Bin Wu, Hua-rong Song, Zheng-rong Xuan. Effect of Sijunzi Decoction and enteral nutrition on T-cell subsets and nutritional status in patients with gastric cancer after operation: A randomized controlled trial. Journal of Chinese Integrative Medicine, 2008, 6(1): 37-40
[6]	Dong Yang, Yong-ping Du, Qing Shen, Wei Chen, Yan Yu, Guang-lei Chen. Expression of alpha-smooth muscle actin in renal tubulointerstitium in patients with kidney collateral stasis. Journal of Chinese Integrative Medicine, 2008, 6(1): 41-44
[7]	Xue-mei Liu, Qi-fu Huang, Yun-ling Zhang, Jin-li Lou, Hong-sheng Liu, Hong Zheng. Effects of Tribulus terrestris L. saponion on apoptosis of cortical neurons induced by hypoxia-reoxygenation in rats. Journal of Chinese Integrative Medicine, 2008, 6(1): 45-50
[8]	SUN Ming-yu, ZUO Jian, DUAN Ji-feng, HAN Jun, FAN Shi-ming, ZHANG Wei, ZHU Li-fang, YAO Ming-hui. Antitumor activities of kushen flavonoids in vivo and in vitro. Journal of Chinese Integrative Medicine, 2008, 6(1): 51-59
[9]	Min Cheng, Qiong Feng, Shu-wen Qian, Hui Gao, Cui-qing Zhu. Preliminary assay of p-amyloid binding elements in heart-beneficial recipe. Journal of Chinese Integrative Medicine, 2008, 6(1): 68-72
[10]	Hai-feng Wei, Bai-liu Ya, Ling Zhao, Cui-fei Ye, Li Zhang, Lin Li. Evaluation of tongue manifestation of blood stasis syndrome and its relationship with blood rheological disorder in a rat model of transient brain ischemia. Journal of Chinese Integrative Medicine, 2008, 6(1): 73-76

Concentration (μg/mL)	n	Inhibition rate
Concentration (μg/mL)	n	12 h	24 h	48 h
Control	3	0	0	0
0.5	3	16.71±2.27*	24.36±2.54^△	29.42±1.88^△
1	3	21.85±1.67*	37.82±1.15^△	44.36±2.35^△
2	3	33.82±2.15*	52.37±1.75^△	60.14±1.36^△
3	3	47.39±2.03*	64.43±2.27^△	76.32±2.33^△
4	3	69.46±1.57*	82.34±0.89^△	90.58±1.18^△

Group	n	Tumor volume
Group	n	Before treatment	8 days after treatment	14 days after treatment	20 days after treatment	26 days after treatment
Normal saline	8	256.3±24.7	636.8±94.1	1 616.6±203.6	3 237.9±382.8	5 768.9±442.8
Blank microspheres	8	249.5±23.3	617.2±88.5	1 572.8±217.2	3 229.5±316.3	5 447.5±426.3
CTX	8	261.3±30.2	459.3±78.4*	842.3±205.2*	1 937.7±257.1*	3 637.5±293.2*
CTX-PLGA	8	251.5±28.4	379.2±58.1**^△	603.2±139.3**^△	915.6±251.2**^△	1 219.6±263.7**^△

Group	n	Body weight ($\bar{x}$±s, g)	Tumor weight ($\bar{x}$±s, g)	Inhibition rate (%)
Normal saline	8	27.90±1.43	2.75±0.52	–
Blank microspheres	8	28.05±0.79	2.51±0.39	8.73
CTX	8	28.29±1.29	2.02±0.46*	26.55
CTX-PLGA	8	28.74±0.70	1.31±0.31**^△	52.36
