Journal of Chinese Integrative Medicine ›› 2011, Vol. 9 ›› Issue (5): 539-545.doi: 10.3736/jcim20110512

• Original Experimental Research • Previous Articles     Next Articles

Effects of Chinese herbal drug-containing serum on oxidative damage and apoptosis of umbilical vein endothelial cells induced by oxidized low-density lipoprotein

Yu Miao, Yue-rong Jiang, Lin Yang, Cheng-dong Xia, Lu Zhang, Cai-feng Wu, Da-zhuo Shi, Hui-jun Yin(), Ke-ji Chen

  1. Center of Cardiovascular Diseases, Xiyuan Hospital, China Academy of Chinese Medical Sciences, Beijing 100091, China
  • Received:2010-11-26 Accepted:2011-01-13 Online:2011-05-20 Published:2011-05-15
  • Contact: Yin Hui-jun

Objective: To investigate the effects of Chinese herbal drug-containing serum, prepared by administration of Chinese herbal medicine for activating blood (Xiongshao Capsule, XS) or for activating blood and detoxifying (Xiongshao Capsule plus Huanglian Capsule, XSHL) in rats, on cell viability, oxidative damage and apoptosis of human umbilical vein endothelial cells (HUVECs) induced by oxidized low-density lipoprotein (ox-LDL).
Methods: Thirty-two rats were randomly divided into 4 groups: control group, positive control group (simvastatin 1.8 mg/kg), activating blood (XS, 0.135 g/kg) group, and activating blood and detoxifying (XS Capsule 0.135 g/kg and Huanglian Capsule 0.135 g/kg, XSHL) group. Corresponding drugs were continuously administered to the rats for 7 days and then drug-containing serum was harvested 1 hour after the last administration. HUVECs isolated from newborn children by collagenase digestion were stimulated by ox-LDL (100 μg/L) and incubated with corresponding drug-containing serum for 24 hours. Untreated HUVECs were also used as a normal control. The morphology and structure of HUVECs were observed by an inverted microscope. Cell viability was measured by methyl thiazolyl tetrazolium method, and cell membrane damage was determined by lactate dehydrogenase (LDH) leakage. Activity of superoxide dismutase (SOD) was examined by spectrophotometry, and content of malondialdehyde (MDA) in the cell lysate was examined by thiobarbituric acid assay. HUVECs were stained with Annexin V-fluorescein isothiocyanate and propidium iodide and analyzed on a flow cytometry to determine apoptosis.
Results: Compared with the normal HUVECs, the cell viability and the activity of SOD were significantly decreased while the content of MDA and apoptosis rate were significantly increased after 24-hour ox-LDL stimulation (P<0.01, P<0.05). Simvastatin-, XS-, and XSHL-containing serum significantly promoted the ox-LDL-stimulated HUVEC viability and inhibited early apoptosis (P<0.01, P<0.05), while had no significant effect on LDH leakage. Simvastatin-containing serum and XS-containing serum also showed significant decrease in MDA content and increase in SOD activity, while XSHL-containing serum showed no significant effects. There was no significant difference between the XS-containing serum group and the XSHL-containing serum group.
Conclusion: Both sera containing XSHL and XS show protective action against the oxidative damage and apoptosis of HUVECs induced by ox-LDL.

Key words: drugs,Chinese herbal, activating blood, detoxication (TCM), endothelial cells, oxidative damage, apoptosis

Figure 1

Morphology of human umbilical vein endothelial cells in different groups (Phase contrast optical microscopy, ×100) A: Blank control group; B: Ox-LDL group; C: 10% simvastatin-containing serum group; D: 10% Xiongshao capsule-containing serum group; E: 10% Xiongshao capsule plus Huanglian capsule-containing serum group."





[1] Sima AV, Stancu CS, Simionescu M . Vascular endothelium in atherosclerosis[J]. Cell Tissue Res, 2009,335(1):191-203
doi: 10.1007/s00441-008-0678-5
[2] Jiang YR, Chen KJ, Xu YG, Yang XH, Yin HJ . Effects of propyl gallate on adhesion of polymorphonuclear leukocytes to human endothelial cells induced by tumor necrosis factor alpha[J]. Chin J Integr Med, 2009,15(1):47-53
doi: 10.1007/s11655-009-0047-3
[3] Vannini N, Pfeffer U, Lorusso G, Noonan DM, Albini A . Endothelial cell aging and apoptosis in prevention and disease: E-selectin expression and modulation as a model[J]. Curr Pharm Des, 2008,14(3):221-225
doi: 10.2174/138161208783413248
[4] Roy Chowdhury SK, Sangle GV, Xie X, Stelmack GL, Halayko AJ, Shen GX . Effects of extensively oxidized low-density lipoprotein on mitochondrial function and reactive oxygen species in porcine aortic endothelial cells[J]. Am J Physiol Endocrinol Metab, 2010,298(1):e89-e98
doi: 10.1152/ajpendo.00433.2009
[5] Lu J, Yang JH, Burns AR, Chen HH, Tang D, Walterscheid JP, Suzuki S, Yang CY, Sawamura T, Chen CH . Mediation of electronegative low-density lipoprotein signaling by LOX-1: a possible mechanism of endothelial apoptosis[J]. Circ Res, 2009,104(5):619-627
doi: 10.1161/CIRCRESAHA.108.190116
[6] Homburg CH, de Haas M, von dem Borne AE, Verhoeven AJ, Reutelingsperger CP, Roos D . Human neutrophils lose their surface Fc gamma RIII and acquire Annexin V binding sites during apoptosis in vitro[J]. Blood, 1995,85(2):532-540
[7] Fan YC, Zhang GP, Tang M, Yu JS, Chen BN . Analysis on mechanism of atherosclerosis from poison[J]. Shandong Zhong Yi Za Zhi, 2004,23(5):261-263
范砚超, 张国平, 唐明, 于俊生, 陈柏楠 . 从毒论治动脉粥样硬化初探[J]. 山东中医杂志, 2004,23(5):261-263
[8] Xu HB, Wu QH . Research and development of Chinese herbs' serum pharmacology[J]. Hunan Zhong Yi Yao Dao Bao, 1999,5(8):11-14
doi: 10.3969/j.issn.1005-9903.2011.10.083
徐海波, 吴清和 . 中药血清药理学研究进展[J]. 湖南中医药导报, 1999,5(8):11-14
doi: 10.3969/j.issn.1005-9903.2011.10.083
