Journal of Chinese Integrative Medicine ›› 2008, Vol. 6 ›› Issue (4): 409-413.doi: 10.3736/jcim20080416

• Original Experimental Research • Previous Articles     Next Articles

Duplication of an animal model of myocardial ischemia with blood stasis syndrome in mini-swines

Wen-yu Xu, Wei Wang(), Shu-zhen Guo, Tao Liu, Lei Liu, Yong-xin Yu

  1. Department of Pharmacology, Basic Medical College, Beijing University of Chinese Medicine, Beijing 100029, China
  • Received:2007-06-07 Online:2008-04-20 Published:2008-04-15
  • Contact: WANG Wei

Objective: To establish an animal model of myocardial ischemia with blood stasis syndrome in mini-swines.
Methods: An animal model of myocardial ischemia was established in mini-swines by oppressing the coronary artery through the expansion of inner layer of Ameroid constrictor and the Ameroid constrictor was implanted into the distal end of the initial part of the first branch of interventricular septum of ramus descendens anterior arteriae coronariae sinistrae. Dynamic observation of behavior changes, general health status and changes of hemorheological parameters in the mini-swines were made after operation.
Results: The coronary angiography showed that the stenosis rate in ischemic group was more than 75% four weeks after operation. Compared with before operation and sham-operated group, there were great changes of behavior, general health status, tongue color and hemorheological parameters in ischemic group (P<0.05).
Conclusion: The animal model of myocardial ischemia with blood stasis syndrome in mini-swines was established successfully 4 weeks after operation. The pathological process in the animal model is similar to that in the patients with chronic myocardial ischemia. So this model can be adopted in the research of myocardial ischemia with blood stasis syndrome.

Key words: myocardial ischemia, blood stasis, models, animal, minipigs

CLC Number:

  • R542.2

Table 1

Ratios of red, blue and green of the tongue color before and after operation in pigs ($\bar{x}$±s)"

Group n Ratio of red Ratio of blue Ratio of green
Before operation 10 0.44±0.03 0.26±0.03 0.30±0.02
2 weeks after operation 10 0.47±0.08 0.27±0.01 0.33±0.06
3 weeks after operation 10 0.48±0.04 0.26±0.02 0.26±0.02
4 weeks after operation 10 0.46±0.03 0.27±0.04 0.29±0.05
Before operation 9 0.52±0.09 0.24±0.01 0.24±0.08
2 weeks after operation 9 0.49±0.01 0.24±0.03 0.27±0.03
3 weeks after operation 9 0.42±0.04** 0.30±0.01** 0.29±0.04*
4 weeks after operation 9 0.43±0.02** 0.30±0.01** 0.27±0.02

Figure 1

Coronary angiography 4 weeks after operation in ischemic group A: Left coronary angiography; B: Right coronary angiography."

Figure 2

Coronary angiography 4 weeks after operation in sham-operated group A: Left coronary angiography; B: Right coronary angiography."

Table 2

Whole blood viscosity before and after operation ($\bar{x}$±s, mPa·s)"

Group n Whole blood viscosity
High (150/s) Middle (38/s) Low (10/s)
Before operation 10 3.14±0.57 4.63±0.80 8.30±1.49
1 week after operation 10 4.23±0.43 6.47±0.50 10.93±0.63**
2 weeks after operation 10 3.97±0.74 5.63±0.75 9.62±0.65
3 weeks after operation 10 3.95±0.40 5.56±0.39 9.42±0.48
4 weeks after operation 10 4.06±0.41 5.89±0.55 10.31±1.09
Before operation 9 3.31±0.41 4.83±0.57 8.64±1.12
1 week after operation 9 4.37±0.36** 6.23±0.45** 10.68±0.89**
2 weeks after operation 9 4.03±0.63** 5.76±0.72** 9.91±0.93*
3 weeks after operation 9 4.42±0.54** 5.96±0.43** 9.96±0.38*
4 weeks after operation 9 3.82±0.65** 5.55±0.84** 9.75±1.46**

Table 3

Plasma viscosity and measured pressure plot before and after operation ($\bar{x}$±s)"

Group n Plasma viscosity (mPa·s) Measured pressure plot (%)
Sham-operated group
Before operation 10 1.54±0.39 42.33±4.41
1 week after operation 10 2.11±0.99 44.63±5.11
2 weeks after operation 10 1.87±0.10 42.00±2.65
3 weeks after operation 10 1.74±0.07 41.25±2.75
4 weeks after operation 10 2.01±0.28 41.33±2.31
Before operation 9 1.78±0.43 40.37±4.24
1 week after operation 9 2.29±0.54 44.50±2.08
2 weeks after operation 9 2.12±0.90 48.40±5.90**
3 weeks after operation 9 1.73±0.16 47.20±3.11**△
4 weeks after operation 9 1.82±0.34 43.88±5.56**

Table 4

Erythrocyte aggregation index, aggregation index integral area, deformation index and deformation index integral area before and after operation ($\bar{x}$±s)"

Group n Aggregation
index (%)
Aggregation index
integral area
index (%)
Deformation index
integral area
Before operation 10 2.28±0.44 457.67±86.57 0.37±0.05 186.42±28.47
1 week after operation 10 2.69±0.47 519.44±53.48 0.32±0.06 173.07±14.23
2 weeks after operation 10 2.61±0.08 523.67±24.83 0.33±0.01 178.67±6.81
3 weeks after operation 10 2.70±0.21 519.00±64.59 0.35±0.05 186.00±34.24
4 weeks after operation 10 2.67±0.30 511.60±67.17 0.38±0.05 198.40±31.30
Before operation 9 2.33±0.45 460.52±88.59 0.38±0.06 195.85±31.16
1 week after operation 9 2.71±0.38 529.25±63.72 0.32±0.10 163.50±60.19
2 weeks after operation 9 2.45±0.19 468.40±45.51 0.36±0.06 170.80±41.51
3 weeks after operation 9 2.68±0.17 526.20±49.96 0.31±0.04* 154.80±30.11*
4 weeks after operation 9 2.50±0.37 492.08±72.34 0.38±0.04 187.60±31.10
[1] Guo ZH . Comprehensive statistical analysis of syndrome differentiation types of traditional Chinese medicine in 2 432 angina pectoris patients with coronary heart disease[J]. Hunan Zhong Yi Za Zhi, 1998,14(2):7-8
郭志华 . 冠心病心绞痛2 432例中医辨证分型综合统计分析[J]. 湖南中医杂志, 1998,14(2):7-8
[2] Liu YJ . The relationship between distribution of traditional Chinese medicine syndrome and the etiology in 382 cases of coronary heart disease[J]. Liaoning Zhong Yi Xue Yuan Xue Bao, 2002,2(4):245-246
刘永家 . 382例冠心病中医证型分布与病因关系[J]. 辽宁中医学院学报, 2002,2(4):245-246
[3] Liu DH, Xu ZZ, Guo WC . Exploration on characteristics of traditional Chinese medicine syndrome types in 395 cases of angina pectoris due to coronary heart disease[J]. Zhong Yi Za Zhi, 1995,36(10):617-618
刘德桓, 许真真, 郭伟聪 . 冠心病心绞痛395例中医证型特点探讨[J]. 中医杂志, 1995,36(10):617-618
[4] Zhu SG, Xiong LH, Xie HF , et al. Establishment of miniature pig model of chronic ischemic heart disease[J]. Zhongguo Lin Chung Kang Fu, 2006,20(10):46-47
祝曙光, 熊利华, 谢鸿发 , 等. 小型猪慢性缺血性心脏病模型的建立[J]. 中国临床康复, 2006,20(10):46-47
[5] Laguens R, Cabeza Meckert P, Vera Janavel G , et al. Entrance in mitosis of adult cardiomyocytes in ischemic pig hearts after plasmid-mediated rhVEGF165 gene transfer[J]. Gene Ther, 2002,9(24):1676-1681
doi: 10.1038/
[6] Chinese Association of Integrative Medicine, Professional Committee of Blood Circulation. Diagnostic criteria of blood stasis[J]. Zhong Xi Yi Jie He Za Zhi, 1987,7(3):129
中国中西医结合研究会活血化瘀专业委员会. 血瘀证诊断标准[J]. 中西医结合杂志, 1987,7(3):129
