Journal of Chinese Integrative Medicine ›› 2007, Vol. 5 ›› Issue (6): 686-691.doi: 10.3736/jcim20070617

Special Issue: Acupuncture & Moxibustion

• Original Experimental Research • Previous Articles     Next Articles

Effect of scalp acupuncture on inflammatory response in rats with acute cerebral ischemia-reperfusion injury

Hong-xing Zhang, Ling-guang Liu, Li Zhou, Hao Huang, Xuan Li, Min Yang

  1. Department of Acupuncture & Moxibustion , Wuhan Chinese and Western Medicine Hospital , Wuhan , Hubei Province 430022 ,China
  • Online:2007-11-20 Published:2007-11-15

Objective To explore the mechanism of scalp acupuncture (SA) in treating cerebral ischemia.Methods: Sixty SD rats with middle cerebral artery occlusion (MCAO) were randomized into untreated group and SA-treated group, with another group of 10 SD rats without artery occlusion as sham-operated control. Neurological severity score (NSS), hemetoxylin and eosin (HE) staining and enzyme-linked immunosorbent assay were applied to observing the changes of neurofunctional defect, inflammatory infiltration in cerebral tissue and content of tumor necrosis factor-α (TNF-α), interleukin-1β (IL-1β) and IL-10 at 24, 48 and 72 h after ischemia-reperfusion.Results: There existed significant difference in NSS between SA-treated group and untreated group (P<0.01), especially at 72 h after ischemia-reperfusion. The HE staining results of ischemic cerebral tissue showed an apparent reduction of inflamed lesions in SA-treated group as compared with the untreated group (P<0.01), especially at 72 h after ischemia-reperfusion. The content of TNF-α and IL-1β at each phase point after ischemia-reperfusion in SA-treated was decreased as compared with that in the untreated group, and there were differences between SA-treated group and untreated group at 72 h after ischemia-reperfusion (P<0.01). An apparent increase was observed in IL-10 between SA-treated group and untreated group at each phase point after ischemia-reperfusion, and there were significant differences between SA-treated group and untreated group at 48 and 72 h after ischemia-reperfusion (P<0.05, P<0.01).Conclusion: Scalp acupuncture can improve neurofunctional rehabilitation, suppress leukocyte infiltration, decrease the content of TNF-α and IL-1β within a certain range and enhance IL-10 expression so as to suppress cytokines-mediated inflammatory reaction and attenuate cerebral ischemia-reperfusion injury.

Key words: scalp acupuncture, brain ischemia, reperfusion, inflammation, rats

CLC Number:

  • R743.31

Table 1

Comparison of neurological severity score among different groups ($\bar{x}±S$)"

Group n NSS
Sham-operated 10 0
24 h after ischemia-reperfusion 10 2.30±0.67**
48 h after ischemia-reperfusion 10 2.10±0.57**
72 h after ischemia-reperfusion 10 2.00±0.47**
24 h after ischemia-reperfusion 10 1.90±0.57**△△
48 h after ischemia-reperfusion 10 1.70±0.48**△△
72 h after ischemia-reperfusion 10 1.30±0.48**△△

Table 2

Number of HE stained inflammatory cells in different groups ($\bar{x}±S$)"

Group n Inflammatory cell number
Sham-operated 10 1.10±0.56
24 h after ischemia-reperfusion 10 12.50±1.27**
48 h after ischemia-reperfusion 10 18.10±1.37**
72 h after ischemia-reperfusion 10 11.10±1.20**
24 h after ischemia-reperfusion 10 12.30±1.25**
48 h after ischemia-reperfusion 10 12.10±1.20**△△
72 h after ischemia-reperfusion 10 7.00±1.41**△△

Figure 1

Brain tissue in different groups (HE staining, ×400)A: Sham-operated group; B: Untreated group at 24 h after ischemia-reperfusion; C: Untreated group at 48 h after ischemia-reperfusion; D: Untreated group at 72 h after ischemia-reperfusion; E: SA-treated group at 24 h after ischemia-reperfusion; F: SA-treated group at 48 h after ischemia-reperfusion; G: SA-treated group at 72 h after ischemia-reperfusion."

Table 3

Plasma content of TNF-α, IL-1β and IL-10 in rats with brain ischemia-reperfusion in different groups (ng/L, $\bar{x}±S$)"

Group n TNF-α IL-1β IL-10
Sham-operated 10 4.94±0.97 56.34±6.31 64.02±9.80
24 h after ischemia-reperfusion 10 7.69±1.44** 66.29±9.78** 138.86±14.66**
48 h after ischemia-reperfusion 10 9.13±1.83* 74.04±7.80** 134.27±13.93**
72 h after ischemia-reperfusion 10 11.37±1.31** 64.12±9.01* 166.55±11.04**
24 h after ischemia-reperfusion 10 6.51±1.36** 65.65±6.31* 143.36±10.76**
48 h after ischemia-reperfusion 10 8.24±1.62** 73.44±6.87** 151.67±15.50**
72 h after ischemia-reperfusion 10 7.08±1.63**△△ 52.57±7.79△△ 196.26±26.02**△△

Table 4

Brain content of TNF-α, IL-1β and IL-10 in rats with brain ischemia-reperfusion in different groups (ng/L, $\bar{x}±S$)"

Group n TNF-α IL-1β IL-10
Sham-operated 10 75.41±10.33 99.31±7.37 95.16±15.20
24 h after ischemia-reperfusion 10 104.79±9.71** 123.09±5.80** 169.74±23.15**
48 h after ischemia-reperfusion 10 125.68±9.11** 139.06±5.93** 234.54±26.40**
72 h after ischemia-reperfusion 10 145.44±17.96** 131.72±5.34** 204.76±24.59**
24 h after ischemia-reperfusion 10 95.31±9.76** 118.90±7.70** 179.80±24.84**
48 h after ischemia-reperfusion 10 117.67±10.69** 135.67±4.02** 276.43±30.35**△△
72 h after ischemia-reperfusion 10 121.74±11.69**△△ 102.69±7.96△△ 235.96±23.47**△△
[1] 王萍 . 头针治疗中风200例临床观察[J]. 针灸临床杂志, 2006,22(12):54-55
Wang P . Clinical observations on 200 patients of apoplexy by head needling[J]. Zhen Jiu Lin Chuang Za Zhi, 2006,22(12):54-55
[2] 张红星, 张唐法 . 头针治疗中风及对血浆内皮素含量的影响[J]. 中国针灸, 2002,22(12):831-832
Zhang HX, Zhang TF . Scalp Acupuncture for Treatment of Apoplexy and Effect on Plasma ET Content[J]. Zhong Guo Zhen Jiu, 2002,22(12):831-832
[3] 张家良, 张小燕 . 头针对急性脑卒中的临床疗效[J]. 中国康复, 2007,22(2):121
Zhang JL, Zhang XY . Clinical Effects of Scalp Acupuncture on Acute stroke[J]. Zhong Guo Kang Fu, 2007,22(2):121
[4] Longa EZ, Weinstein PR, Carlson S , et al. Reversible middle cerebral artery occlusion without craniectomy in rats[J]. Stroke, 1989,20(1):84-91
[5] 华兴邦 . 大鼠穴位图谱的研制[J]. 实验动物与动物实验, 1991,( 1):1-5
Hua XB . Design of Rat Acupoint[J]. AtlasShi Yan Dong Wu Yu Dong Wu Shi Yan, 1991,( 1):1-5
[6] Lu A, Tang Y, Ran R , et al. Genomics of the Periinfarction Cortex After Focal Cerebral Ischemia[J]. J Cereb Blood Flow Metab, 2003,23(7):786-810
doi: 10.1097/01.WCB.0000062340.80057.06 pmid: 12843783
[7] Mergenthaler P, Dirnagl U, Meisel A . Pathophysiology of Stroke: Lessons from Animal Models[J]. Metab Brain Dis, 2007,19(3-4):151-167
[8] 罗梅宏, 周永明 . 中药抗组织损伤与白细胞黏附[J]. 中西医结合学报, 2005,3(4):322-325
Luo MH, Zhou YM . Leukocyte adhesion and prevention of tissue injury with traditional Chinese medicine[J]. Zhong Xi Yi Jie He Xue Bao, 2005,3(4):322-325
[9] 梁健芬, 董少龙, 窦维华 , 等. 水蛭注射液对大鼠脑缺血再灌注后TNF-α、IL—1β和ICAM-1蛋白表达的影响[J]. 陕西医学杂志, 2006,35(12):1605-1607
Liang JF, Dong SL, Dou WH, Hu YQ . Effects of ShuiZhi Injection on TNF-α, IL-lβ and ICAM-1 Expression in Rats with Cerebral Ischemic Reperfusion Injury[J]. Shan Xi Yi Xue Za Zhi, 2006,35(12):1605-1607
[10] Feuerstein G, Wang X, Barone F . Cytokins in brain ischemia: the role of TNF-alpha. Cell Mol Neurobiol[J]. Shan Xi Yi Xue Za Zhi, 1998,18(6):695-701
[11] Fabian RH, Perez-Polo JR, Kent TA . Electrochemical monitoring of superoxide anion production and cerebral blood flow: effect of interleukin-1 beta pretreatment in a model of focal ischemia and reperfusion[J]. J Neurosci Res, 2000,60(6):795-803
[12] 曲东锋, 倪长江, 李宏建 . 卒中后炎症反应——有益还是有害?[J]. 国外医学脑血管疾病分册, 2002,10(5):343-344
Qu DF, Ni CJ, Li HJ . Inflammation after stroke: beneficial or malefic?[J]. Guo Wai Yi Xue Nao Xue Guan Ji Bing Fen Ce, 2002,10(5):343-344
[13] 陈燕启, 刘德红, 姜宏志 , 等. 葛根素对脑缺血-再灌流时大鼠肿瘤坏死因子α和白细胞介素-1β表达的影响[J]. 中华急诊医学杂志, 2005,14(2):119-121
Chen YQ, Liu DH, Jiang HZ, Yang GT . Effects of puerarin on TNF-α mRNA and IL -1β mRNA in Rats after global cerebral ischemia-reperfusion[J]. Zhong Hua Ji Zhen Yi Xue Za Zhi, 2005,14(2):119-121
[14] Wang Q, Tang XN, Yenari MA . The inflammatory response in stroke[J]. J Neuroimmunol, 2007,184(1-2):53-68
doi: 10.1016/j.jneuroim.2006.11.014 pmid: 17188755
[15] van Exel E, Gussekloo J, de Craen AJ, at al . Inflammation and stroke: the Leiden 85-Plus Study[J]. Stroke, 2002,33(4):1135-1138
doi: 10.1161/01.STR.0000014206.05597.9E pmid: 11935072
[16] Murakami Y, Saito K, Hara A , et al. Increases in tumor necrosis factor-alpha following transient global cerebral ischemia do not contributes to neuron death in mouse hippocampus[J]. J Neurochem, 2005,93(6):1616-1622
[17] Offner H, Subramanian S, Parker SM , et al. Experimental stroke induces massive, rapid activation of the peripheral immune system[J]. J Cereb Blood Flow Metab, 2006,26(5):654-665
[18] Skifter DA, Allegrini PR, Wiessner C , et al. Similar Time-Course of Interleukin-1Beta Production and Extracellular-Signal-Regulated kinase(ERK) Activation in Permanent Focal brain Ischemic Injury[J]. Metab Brain Dis, 2002,17(3):131-138
doi: 10.1023/A:1019917803470
[19] Haqqani AS, Nesic M, Preston E , et al. Characterization of vascular protein expression patterns in cerebral ischemia/reperfusion using laser capture microdissection and ICAT-nanoLC-MS/MS[J]. FASEB J, 2005,19(13):1809-1821
[20] 王文华, 卞杰勇, 王中 , 等. 大鼠永久性脑缺血后白细胞介素IL-1β表达的研究[J]. 苏州大学学报(医学版), 2005,25(6):986-988
Wang WH, Bian JY, Wang Z , et al. Interleukin-1β mRNA Expression after Permanent Cerebral Ischemia in Rats[J]. Suzhou Da Xue Xue Bao(Yi Xue Ban), 2005,25(6):986-988
[21] Li HL, Kostulas N, Huang YM , et al. IL-17 and IFN-gamma mRNA expression is increased in the brain and systemically after permanent middle cerebral artery occlusion in the rat[J]. J Neuroimmunol, 2006,116(1):5-14
[22] Zhai QH, Futrell N, Chen FJ . Gene expression of IL-10 in relationship to TNF-alpha, IL-1beta and IL-2 in the rat brain following middle cerebral artery occlusion[J]. J Neurol Sci, 1997,152(2):119-124
[23] 张红星, 周利, 张唐法 . 头针对大鼠急性局灶性脑缺血再灌注损伤的影响[J]. 浙江中西医结合杂志, 2006,16(5):268-269
Zhang HX, Zhou L, Zhang TF . Effect of Scalp Acupuncture on Cerebral Blood Flow of the Rat Model with Acute Regional Cerebral Ischemia and Reperfusion Injury[J]. Zhejiang Zhong Xi Yi Jie He Za Zhi, 2006,16(5):268-269
[24] 周利, 张红星, 张唐法 . 头针治疗卒中易感型自发性高血压大鼠的实验研究[J]. 上海针灸杂志, 2006,25(6):42-44
Zhou L, Zhang HX . Study of Scalp Acupuncture on Spontaneous Hypertensive Rats-Stroke Prone after Stroke[J]. Shanghai Zhen Jiu Za Zhi, 2006,25(6):42-44
[25] 吴广伟 . 针刺治疗缺血性脑中风30例疗效观察[J]. 国际医药卫生导报, 2006,12(22):79-80
Wu GW . Observation of Acupuncture on 30 Patients with Ischemic Stroke.[J]. Guo Ji Yi Yao Wei Sheng Dao Bao, 2006,12(22):79-80
