Journal of Chinese Integrative Medicine ›› 2010, Vol. 8 ›› Issue (10): 961-967.doi: 10.3736/jcim20101008

• Original Experimental Research • Previous Articles     Next Articles

Effects of Chinese herbal medicine Shenlong Decoction on mRNA expressions of matrix metalloproteinase-2 and tissue inhibitor of metalloproteinase-1 in lung tissue of rats with pulmonary fibrosis induced by bleomycin

 Xiao-dong Lua, Li-jian Pangb, Lin-lin Wangb,Ming-hua Nana, Zhi Mab

  1. a Department of Respiratory Diseases, the Second Affiliated Hospital, Liaoning University of Traditional Chinese Medicine, Shenyang 110034, Liaoning Province, China
    b Department of Respiratory Diseases, Affiliated Hospital, Liaoning University of Traditional Chinese Medicine, Shenyang 110032,Liaoning Province,China
  • Received:2010-03-31 Accepted:2010-06-26 Online:2010-10-20 Published:2010-10-15


To observe the expressions of matrix metalloproteinase-2 (MMP-2) and tissue inhibitor of metalloproteinase-1 (TIMP-1) in rats with pulmonary fibrosis (PF) induced by bleomycin, and to explore the mechanisms of Shenlong Decoction in preventing and treating PF.

A total of 230 Wistar rats were divided into normal control group, untreated group, prednisone group, and low-, medium- and high-dose Shenlong Decoction groups. Wistar rats were intratracheally injected with bleomycin to induce PF. From the 2nd day, rats in the normal control and untreated groups were lavaged with normal saline (NS), and rats in the other groups were lavaged with prepared Shenlong Decoction by the same amount. Hemotoxylin-eosin (HE) staining and Masson staining were used to observe pathological changes in lung tissue at different time points, and to evaluate whether the model was successfully induced. Expressions of MMP-2 and TIMP-1 mRNAs in rats’ lung tissue were measured by reverse transcription-polymerase chain reaction (RT-PCR).

Expressions of MMP-2 and TIMP-1 mRNAs in lung tissue of rats were observed from all groups at each time point. In comparison with the normal control group, on the 7th day, the transcription levels of MMP-2 and TIMP-1 mRNAs, especially the former, of the untreated group increased significantly (P<0.05 or P<0.01). On the 14th day, the transcription levels of MMP-2 and TIMP-1 mRNAs kept rising, especially the latter (P<0.05 or P<0.01). On the 28th day, the transcription level of MMP-2 decreased a little, while the transcription level of TIMP-1 mRNA did not stop increasing (P<0.05 or P<0.01). Compared with the untreated group, decrease of the transcription levels of MMP-2 and TIMP-1 mRNAs were observed in the treatment groups, especially the former, and this effect continued to the 28th day with the medium-dose Shenlong Decoction group decreasing most obviously (P<0.05 or P<0.01).

Shenlong Decoction may inhibit the expression of MMP-2 mRNA by up-regulating the expression of TIMP-1 mRNA so as to slow the progression of PF.

Key words: Pulmonary fibrosis, Bleomycin, Matrix metalloproteinase-2, Tissue inhibitor of metalloproteinase-1, Rats

Figure 1

Pathological changes in lung tissue of rats in untreated group observed by HE staining (Light microscopy,×200) A: 7th d; B: 14th d; C: 28th d."

Figure 2

Pathological changes in lung tissue of rats in untreated group observed by Masson staining (Light microscopy,×200) A: 7th d; B: 14th d; C: 28th d."



Figure 3

Expressions of MMP-2 and TIMP-1 mRNAs in lung tissue of rats in different groups at different time points A: Normal control group; B: Untreated group; C: High-dose SLD group; D: Medium-dose SLD group; E: Low-dose SLD group; F: Prednisone group. GAPDH: 500 bp; MMP-2 mRNA: 380 bp; TIMP-1 mRNA: 391 bp."

[1] Hayashi T, Stetler-Stevenson WG, Fleming MV, Fishback N, Koss MN, Liotta LA, Ferrans VJ, Travis WD . Immunohistochemical study of metalloproteinases and their tissue inhibitors in the lungs of patients with diffuse alveolar damage and idiopathic pulmonary fibrosis[J]. Am J Pathol, 1996,149(4):1241-1256
[2] O’Connor CM, FitzGerald MX . Matrix metalloproteases and lung disease[J]. Thorax, 1994,49(6):602-609
doi: 10.1136/thx.49.6.602
[3] Szapiel SV, Elson NA, Fulmer JD, Hunninghake GW, Crystal RG . Bleomycin-induced interstitial pulmonary disease in the nude, athymic mouse[J]. Am Rev Respir Dis, 1979,120(4):893-899
doi: 10.1164/arrd.1979.120.4.893 pmid: 92208
[4] Miao MS. Experimental animal and animal experiment techniques[M]. Beijing: China Press of Traditional Chinese Medicine,2003: 142-145
苗明三 . 实验动物和动物实验技术[M]. 北京: 中国中医药出版社,2003: 142-145
[5] Liu JM, Yan QH, Lu YJ. Theory, method and application of pathological tissue staining[M]. Beijing: People’s Medical Publishing House,1983: 45-48
刘介眉, 严庆汉, 路英杰 . 病理组织染色的理论方法和应用[M]. 北京: 人民卫生出版社,1983: 45-48
[6] Clark JG, Kostal KM, Marino BA . Bleomycin-induced pulmonary fibrosis in hamsters. An alveolar macrophage product increases fibroblast prostaglandin E2 and cyclic adenosine monophosphate and suppresses fibroblast proliferation and collagen production[J]. J Clin Invest, 1983,72(6):2082-2091
doi: 10.1172/JCI111173
[7] Xu ZD, Zhang YE, Chen ZN, Xu YD, Zhang XR, Wang XH . The changes of pulmonary interstitial cells during bleomycli-induced lung fibrosis in rats[J]. Shanghai Yi Ke Da Xue Xue Bao, 1995,22(2):93-96
doi: 10.1007/BF02007173
许祖德, 张月娥, 陈忠年, 徐元鼎, 张秀荣, 王新禾 . 博莱霉素诱发大鼠肺纤维化时肺内间质细胞的变化[J]. 上海医科大学学报, 1995,22(2):93-96
doi: 10.1007/BF02007173
[8] Gomez DE, Alonso DF, Yoshiji H, Thorgeirsson UP . Tissue inhibitors of metalloproteinases: structure, regulation and biological functions[J]. Eur J Cell Biol, 1997,74(2):111-122
pmid: 9352216
[9] Ishiguro N, Ito T, Oguchi T, Kojima T, Iwata H, Ionescu M, Poole AR . Relationships of matrix metalloproteinases and their inhibitors to cartilage proteoglycan and collagen turnover and inflammation as revealed by analyses of synovial fluids from patients with rheumatoid arthritis[J]. Arthritis Rheum, 2001,44(11):2503-2511
doi: 10.1002/(ISSN)1529-0131
[10] Nagase H, Woessner JF Jr . Matrix metalloproteinases[J]. J Biol Chem, 1999,274(31):21491-21494
doi: 10.1074/jbc.274.31.21491
[11] Sternlicht MD, Werb Z .How matrix metalloproteinases regulate cell behavior[J].Annu Rev Cell Dev Biol, 2001, 17: 463-516
doi: 10.1146/annurev.cellbio.17.1.463 pmid: 11687497
