Journal of Chinese Integrative Medicine ›› 2011, Vol. 9 ›› Issue (9): 991-996.doi: 10.3736/jcim20110910

• Original Experimental Research • Previous Articles     Next Articles

Protective effects of Chinese herbal medicine Zuogui Pill on retina ganglion cells after optical nerve clipping injury in rats

Yong-qian Wang1(), Xiao-feng Li2, Xin Zhou3, Xin-quan Liu4, Wei-ping Wang1

  1. 1. Department of Neurosurgery, Longhua Hospital, Shanghai University of Traditional Chinese Medicine, Shanghai 200032, China
    2. Institute of Spine Diseases, Shanghai University of Traditional Chinese Medicine, Shanghai 200032, China
    3. Department of Pharmacy, Longhua Hospital, Shanghai University of Traditional Chinese Medicine, Shanghai 200032, China
    4. Department of Ophthalmology, Longhua Hospital, Shanghai University of Traditional Chinese Medicine, Shanghai 200032, China
  • Received:2011-04-04 Accepted:2011-05-09 Online:2011-09-20 Published:2011-09-15
  • Contact: Wang Yong-qian E-mail:sunmoonciel@163.com

Objective: To investigate the protective effects of Zuogui Pill (ZGP), a compound Chinese herbal medicine, on retina ganglion cells (RGCs) in rats after optical nerve clipping injury.

Methods: Optic nerves in Sprague-Dawley rats were crushed intraorbitally at 2 mm behind eyeball by using a forceps with a 140-gram chucking power for 30 s to induce unilateral injured model. The injured rats were fed with ZGP (ZGP group, 4.0 g/kg body weight each day) and equal volume of normal saline (injury group) respectively. Morphological changes in the retina were observed and the RGCs were quantified in the specimens. Nestin and glial fibrillary acidic protein (GFAP) expressions in the retina were detected by immunohistochemical fluorescence staining at different time points after nerve injury.

Results: After optical never crushing, the thickness of retina and the number of RGCs were significantly decreased in injury group as compared with the normal group. Nearly 50% of the total RGCs were disappeared at the 4th week in the injury group. The expression levels of nestin and GFAP in the retina were markedly increased after optical never crushing at the 2nd week and this lasted to the 8th week, and gradually decreased to the normal level at the 16th week. In contrast, the arrangement of retinal cells was regular in the ZGP group, and the number of survival RGCs was greater than that of the injury group. Meanwhile, the nestin and GFAP expressions in retina were significantly enhanced as compared with the injury group at all time points.

Conclusion: ZGP may have proctective effects on rat optic nerve and RGCs after contusion by promoting the nestin and GFAP expressions in Muller cells of the retina.

Key words: Zuogui Pill, drugs,Chinese herbal, retina, retinal ganglion cells, optic nerve injury, nestin, glial fibrillary acidic protein, rats

Table 1

Numbers of RGCs in retina at different time points after optic nerve crush in adult rats ($\overline{x}$±s)"

Group n Number of RGCs
1 week 2 weeks 4 weeks 8 weeks 16 weeks
Normal 5 40.13±5.42
Sham injury 5 40.07±4.65
Injury 3 31.27±3.57** 24.00±3.38** 19.93±2.15** 17.13±2.13** 15.00±2.51**
ZGP 3 34.60±3.79**△ 28.07±3.41**△△ 24.20±2.36**△△ 20.93±2.37**△△ 17.26±2.63**△

Table 2

IOD of nestin immunoreactivity in retina after optic nerve crush in adult rats ($\overline{x}$±s)"

Group n IOD of nestin
1 week 2 weeks 4 weeks 8 weeks 16 weeks
Normal 5 0.013±0.004
Sham injury 5 0.015±0.004
Injury 3 0.023±0.007** 0.028±0.005** 0.037±0.006** 0.029±0.006** 0.015±0.005
ZGP 3 0.029±0.007**△ 0.036±0.006**△△ 0.043±0.006**△△ 0.033±0.006**△△ 0.022±0.005**△△

Table 3

IOD of GFAP immunoreactivity in retina after optic nerve crush in adult rats ($\overline{x}$±s)"

Group n IOD of GFAP
1 week 2 weeks 4 weeks 8 weeks 16 weeks
Normal 5 0.012±0.005
Sham injury 5 0.013±0.007
Injury 3 0.024±0.008** 0.031±0.005** 0.037±0.006** 0.030±0.006** 0.019±0.005*
ZGP 3 0.031±0.008**△ 0.037±0.006**△△ 0.044±0.007**△△ 0.034±0.006**△ 0.024±0.006**△

Figure 1

Expressions of DAPI, nestin and GFAP in retina tissues of rats observed by immunofluorescence method A: Nestin expression in the normal group; B: GFAP expression in the normal group; C: Nestin expression in the injury group at the 4th week after injury; D: GFAP expression in the injury group at the 4th week after injury; E: Nestin expression in the Zuogui Pill group at the 4th week after injury; F: GFAP expression in the Zuogui Pill group at the 4th week after injury. Nestin expression was stained with green, NAPI with blue and GFAP with red. ZGP: Zuogui Pill; GFAP: glial fibrillary acidic protein; DAPI: 4′,6-diamidino-2-phenylindole; GCL: retinal ganglion cell layer; INL: inner nuclear layer; IPL: inner plexiform layer; ONL: outer nuclear layer. Arrows point to the positive processes in the IPL. Scale bar=50 μm."

[1] Harvey AR, Hu Y, Leaver SG, Mellough CB, Park K, Verhaagen J, Plant GW, Cui Q . Gene therapy and transplantation in CNS repair: the visual system[J]. Prog Retin Eye Res, 2006,25(5):449-489
doi: 10.1016/j.preteyeres.2006.07.002 pmid: 16963308
[2] Dahlmann-Noor AH, Vijay S, Limb GA, Khaw PT . Strategies for optic nerve rescue and regeneration in glaucoma and other optic neuropathies[J]. Drug Discov Today, 2010,15(7-8):287-299
doi: 10.1016/j.drudis.2010.02.007 pmid: 20197108
[3] Zhou YH, Liu W . Study approaches of promoting regeneration of central nerves by Chinese herbs[J]. Shandong Zhong Yi Yao Da Xue Xue Bao, 2004,28(6):410-412
周永红, 刘伟 . 中药促进中枢神经再生的研究思路和方法[J]. 山东中医药大学学报, 2004,28(6):410-412
[4] Chen Q. Methodology of research on pharmacology of traditional Chinese medicine[M]. Beijing: People’s Medical Publishing House, 1993, 31-35
陈奇 . 中药药理研究方法学[M]. 北京: 人民卫生出版社, 1993, 31-35
[5] Gellrich NC, Schimming R, Zerfowski M, Eysel UT . Quantification of histological changes after calibrated crush of the intraorbital optic nerve in rats[J]. Br J Ophthalmol, 2002,86(2):233-237
doi: 10.1136/bjo.86.2.233
[6] Zhang JJ . Advances in astrocytes[J]. Zhongguo Yao Li Xue Tong Bao, 2006,22(7):788-791
doi: 10.3321/j.issn:1001-1978.2006.07.005
张敬军 . 星形胶质细胞的研究[J]. 中国药理学通报, 2006,22(7):788-791
doi: 10.3321/j.issn:1001-1978.2006.07.005
[7] Xue LP, Lu J, Cao Q, Kaur C, Ling EA . Nestin expression in Müller glial cells in postnatal rat retina and its upregulation following optic nerve transection[J]. Neuroscience, 2006,143(1):117-127
doi: 10.1016/j.neuroscience.2006.07.044
[8] Wohl SG, Schmeer CW, Kretz A, Witte OW, Isenmann S . Optic nerve lesion increases cell proliferation and nestin expression in the adult mouse eye in vivo[J]. Exp Neurol, 2009,219(1):175-186
doi: 10.1016/j.expneurol.2009.05.008
[9] Wang X, Tay SS, Ng YK . An immunohistochemical study of neuronal and glial cell reactions in retinae of rats with experimental glaucoma[J]. Exp Brain Res, 2000,132(4):476-484
doi: 10.1007/s002210000360
[10] Meng FX, Zhang PY, Cheng C, Cao Z, Tan XL, Gu XS . A study of using neurons cell culture to search for the effect of single Chinese herb on nerve growth[J]. Nantong Yi Xue Yuan Xue Bao, 1999,19(1):14-16
孟凡迅, 张沛云, 程纯, 曹铮, 谭湘陵, 顾晓松 . 神经细胞培养法观察单味中药促神经生长的研究[J]. 南通医学院学报, 1999,19(1):14-16
[11] Zhang TT, Su XW, Jiang WJ, Huang YJ, Qiu PX, Yan GM . Zuogui pill protects rat cerebellar granule neurons from apoptosis induced by glutamate[J]. Zhongguo Shi Yan Fang Ji Xue Za Zhi, 2003,9(5):15-18
doi: 10.3969/j.issn.1005-9903.2003.05.008
张涛涛, 苏兴文, 江伟健, 黄奕俊, 邱鹏新, 颜光美 . 左归丸加减方对谷氨酸诱导的体外培养大鼠小脑颗粒神经元凋亡影响[J]. 中国实验方剂学杂志, 2003,9(5):15-18
doi: 10.3969/j.issn.1005-9903.2003.05.008
